| 400G QSFP-DD SR8 | |||
| PN | SWD88P8-KCP1 | Vendor Name | Sanweiphotonics |
| Package | QSFP-DD | Data Rate | 400Gbps |
| Wavelength | 850nm | Distance | 100m |
| Connector | MTP/MPO-16 (APC) | Media | MMF |
| AOP | -6~4dBm | SEN | -7.9~4dBm |
| Power Consumption | ≤10W | ER | ＞3dB |
| Temperature | 0 to 70°C | Modulation | 8x 50G PAM4 |
| 400G QSFP112 SR4 | |||
| PN | SWD88Q4-QCP1 | Vendor Name | Sanweiphotonics |
| Package | QSFP112 | Data Rate | 425Gbps |
| Wavelength | 850nm | Distance | 100m |
| Connector | MTP/MPO-12 (APC) | Media | MMF |
| AOP | -4.5~4dBm | SEN | -6.4~4dBm |
| Power Consumption | ≤10W | ER | ＞2.5dB |
| Temperature | 0 to 70°C | Modulation | 4x 100G PAM4 |
| 400G QSFP-DD DR4 | |||
| PN | SWD11Q4-KCP5 | Vendor Name | Sanweiphotonics |
| Package | QSFP-DD | Data Rate | 425Gbps |
| Wavelength | 1310nm | Distance | 500m |
| Connector | MTP/MPO-12 (APC) | Media | SMF |
| AOP | -2.8~4.0dBm | SEN | -6~4dBm |
| Power Consumption | ≤10W | ER | ＞3.5dB |
| Temperature | 0 to 70°C | Modulation | 4x 100G PAM4 |
| 400G QSFP-DD FR4 | |||
| PN | SWDCWQ4-KC02 | Vendor Name | Sanweiphotonics |
| Package | QSFP-DD | Data Rate | 425Gbps |
| Wavelength | 1271-1331nm | Distance | 2km |
| Connector | MTP/MPO-12 (APC) | Media | SMF |
| AOP | -3.3~3.5dBm | SEN | -7.3~3.5dBm |
| Power Consumption | ≤10W | ER | ＞3.5dB |
| Temperature | 0 to 70°C | Modulation | 4x 100G PAM4 |
